Connect Databricks as a Data Source

Zuar Portal supports Databricks as a data source. Databricks is configured like any other external database: you store a connection string in a Database Connection Named Credential and assign it to a data source. There is no separate "Databricks" option to select — the connection type is determined by the connection string.

Prerequisites

• A running Databricks SQL warehouse. A stopped warehouse cannot answer queries, so enable auto-resume or start it before running queries.
• Your Databricks server hostname, the warehouse HTTP path, and a personal access token (PAT).

Create the connection

1. Open the admin console and go to Named Credentials.
2. Click New Credential and choose the Database Connection type.

3. Enter the connection string in the following form:

   databricks://token:<PAT>@<server-hostname>?http_path=<http_path>


   For example:

   databricks://token:dapiXXXXXXXXXXXXXXXX@dbc-1234abcd-5678.cloud.databricks.com?http_path=/sql/1.0/warehouses/abc123def456


   The username is the literal word token, and the password is your personal access token. Find the hostname and HTTP path in your Databricks workspace under SQL Warehouses → (your warehouse) → Connection details.

4. Save the credential.

Use it in a data source

1. Create or edit a data source.
2. Set its Database to the Databricks credential you created.
3. Enter your SELECT query and click Test to verify the connection.

Notes and caveats

Databricks SQL differences

• Use STRING or VARCHAR instead of CHAR — Databricks requires a length on CHAR.
• Timestamp columns are returned as UTC-aware values.
• Queries fail when the SQL warehouse is stopped; start it or enable auto-resume.
